ND95PD Classroom Security Lock
ND95PD ANSI F110
Classroom Security Lock
Key in either lever locks or unlocks outside lever.
Inside lever is always unlocked.
Standard Features:
Certification Exceeds ANSI A156.2, Series 4000, Grade 1,
UL Listed for 3 hour fire door. Meets A117.I
Feature Tested to exceed three million cycles
Latch 1-1/8” x 2-1/4”, Square corner faceplate, 1” housing diameter, 1/2” throw
Strike 1-1/4” x 4-7/8”, ANSI, Square corner, no box
Backset 2-3/4” standard, other backsets available
Cylinder Classic C keyway, also available C123 Everest Keyway
Door Range 1-5/8” - 2-1/8”
Options:
• Available prepped for Removable Core ( RC) less core; specify “J”
• Available prepped F/ Best IC Core (Small Format) less core specify “B”
