Z Series Grade 1 Cylindrical Lockset
- Meets & Exceeds ANSI - A156.2, Series 4000, Grade 1 Standards
- UL Listed for "A" Label 3 Hour Fire Doors
- Meets ADA and ANSI A117.1 accessibility codes
- Tested to over 2 Million Cycles
- Steel, Zinc dichromated chassis for Corrosion Resistance
- Clutching levers standard for Vandal resistance on locking functions
- 5" Solid zinc diecast levers, 3 1/2" wrought brass roses
- Independent lever return springs to prevent lever sag
- Non-Handed - Completely reversible
- 2 3/4" backset std. with 1 1/8" x 2 1/4" latchface, 2 3/8" backset is available with
- 1" x 2 1/4" latchface both with self adjusting front for square or beveled edge doors
- Stainless Steel Latch bolt with 1/2" projection, Deadlocking on keyed functions
- 6 Pin Brass, C Kwy, with 2 Keys std, Prepared for Small format IC core (less core)
- Strikes: 4 7/8" x 1 1/4" ASA standard - T strike & Full lip strikes available when specified
- Door Prep: ANSI A115.2 - 2 1/8" crossbore with (2) 5/16" Thru bolt holes
- Factory Set for 1 3/4" thick doors - can be adjusted to fit 1 3/8" to 2" thick doors
- Lever Styles: Flat (standard, shown above), Curved & Half Curved
- Finishes: US26D in stock
- Special Order Finishes: US3 PVD*, US4, US10B, US15, US26 PVD* (PVD = Lifetime Finish)(12 week lead time)
- Fasteners: Combination screws for wood or metal doors & frames
- Electrified Options: 12 or 24 Volt (AC/DC) Fail Safe (Electrically Locked), Fail Secure (Electrically Unlocked)
- REX - Request to exit switch, Optional
- Limited Lifetime Warranty
- Meets & Exceeds ANSI - A156.2, Series 4000, Grade 1 Standards
- UL Listed for "A" Label 3 Hour Fire Doors
- Meets ADA and ANSI A117.1 accessibility codes
- Tested to over 2 Million Cycles
- Steel, Zinc dichromated chassis for Corrosion Resistance
- Clutching levers standard for Vandal resistance on locking functions
- 5" Solid zinc diecast levers, 3 1/2" wrought brass roses
- Independent lever return springs to prevent lever sag
- Non-Handed - Completely reversible
- 2 3/4" backset std. with 1 1/8" x 2 1/4" latchface, 2 3/8" backset is available with
- 1" x 2 1/4" latchface both with self adjusting front for square or beveled edge doors
- Stainless Steel Latch bolt with 1/2" projection, Deadlocking on keyed functions
- 6 Pin Brass, C Kwy, with 2 Keys std, Prepared for Small format IC core (less core)
- Strikes: 4 7/8" x 1 1/4" ASA standard - T strike & Full lip strikes available when specified
- Door Prep: ANSI A115.2 - 2 1/8" crossbore with (2) 5/16" Thru bolt holes
- Factory Set for 1 3/4" thick doors - can be adjusted to fit 1 3/8" to 2" thick doors
- Lever Styles: Flat (standard, shown above), Curved & Half Curved
- Finishes: US26D in stock
- Special Order Finishes: US3 PVD*, US4, US10B, US15, US26 PVD* (PVD = Lifetime Finish)(12 week lead time)
- Fasteners: Combination screws for wood or metal doors & frames
- Electrified Options: 12 or 24 Volt (AC/DC) Fail Safe (Electrically Locked), Fail Secure (Electrically Unlocked)
- REX - Request to exit switch, Optional
- Limited Lifetime Warranty
